Coated aluminium foil for pharmaceutical packaging
Chalco Aluminum coat’s coated aluminium foil could be used for the production of protective and safe packaging for pharmaceutical applications. Moreover it can be made suitable for different applications like”push through” lids or preformed trays for tablets by using different alloys with different mechanical properties, such as blister packs for pharmaceutical applications; cold forming blister packaging, push through “lids”.
Features:
1.Total barrier protection against light, moisture, oxygen and other gases, and liquids.
2.Good mechanical protection.
3.Light weight that allows use the minimum of transport and production space.
4.Safe for use in contact with foodstuffs according to FDA.
Specification:
Alloy: 8011, 8079
Temper: O, H18
Thickness: 0.02mm up to 0.05mm.
Coating properties: Colorless primer and coloured lacquer
1.Excellent adhesion to aluminium foil
2.Good printing results using nitrocellulose links and UV inks.
3.Resistant to heatsealing temperature.(Max. 220℃ 1s)
4.Water resistant (30 minute at room temperature)
Heat sealing lacquers:
1.Authorized for contact with foodstuffs. ( FDA)
2.Water resistant ( 30 minute at room temperature)
3.Resistant to boiling water ( 5 min/100 ℃)
4.Lacquer porosity (15 min)< 5 pores/m2(20g CuSO4/50cc HCL(35%)/1000 cc. H2O).
5.Sealable to PVC/PVDC. Peel strength to PVC >7.5 N/15mm. (180℃, 40kg,1s)
